Commercial Divider Curtains

Rolling Hardware

• 16 gauge galvanized steel tracks
• Nylon roller hooks for easy opening
• 6 mounting styles to connect to various structures
• Free standing hardware for up to 20' in height

Drop Ceiling Mount

• Chain or Cable Track Hardware is made just for drop ceilings.
• Cables are dropped down from the structure above at any height.
• Track support tab sticks above the ceiling tiles for a clean install.
• Heavier-duty than aluminum and light I-Beam tracks

Need Portable and Free Standing?

If you need to create a portable and free-standing church backdrop or dividers, please see this page.

Width

• Measure the distance that you are trying to cover and then input that dimension and enter it into the width box.

Height

• Measure the distance from the floor to the above mounting point (from where you would attach the curtain track) and subtract 2 inches, and then input it into the height box.
• TIP - If you are not using any hardware, then you don't need to subtract the 2"

Common Questions

• Standard curtains have approximately 3.75 to 1″ of a gap from the bottom of the track to the top of the curtain.

What are the dimensions of the track?

• Yes, the track is made to be field cut on site using a hack saw or sawzall.

• The track is modular in design and will arrive in pieces that have a simple bolt-together design.

• The track should be supported approximately every 5' with a track support. The farther apart the track supports, the greater the deflection. If you have a relatively lightweight curtain, then you could space the supports out to about 8' apart. You will receive enough track supports with your order to achieve this 5' spacing.

• Yes. This is called a flush-mount installation and is very common. Simply drill through the middle of the track and use a small wood screw, bolt, Tek screw,  etc. into your structure. Space the holes about every 3-5'.

• It is very easy. All components simply fit together and connect with set screws. The installation is very intuitive. If you have any difficulty, simply call or email us, and we will walk you through the process.

Key Benefits

• Less expensive than rigid walls
• Can be taken down quickly when not needed
• Can be re-purposed in other areas
• Ability to purchase more curtains and attach to existing curtains
• Divide work areas quickly
• Industrial blackout curtains improve worker safety
• Quick to roll out of way when not in use
• Easy to clean with slick surface of the vinyl style
• Lifetime warranty on all hardware and 5 year warranty on curtains

Many Layout Options

AKON can supply just about any layout you can think of. Below are some common styles. They can be single sided, double-sided, triple sided, four-sided or multiple straights to create complete enclosures. You simply inform AKON about your desired design and we will have it fabricated exactly as you need it. For customized layouts, sketch your design and upload it using our online RFQ form. See link below.

Lead Time

• Ships in 7-10 work days
• Ships UPS or FedEx. You can also specify your shipping account

Warranty

• Curtains - 10 year warranty on manufacturing defects
• Hardware - Lifetime warranty on manufacturing defects
