Description
Measuring Choosing The Correct Strips Hardware Material FAQ Ordering Measuring
Step 1 – Width x Height
- Measure the width and the height of the door
opening or area where you want to install the
strips. - Add 6″ more in total height and add 6″ total in width
if you want wall mount hardware
Step 2 – Choose Your Hardware
- Decide on the type of mounting that best fits
your application- Wall mount is preferred on doorways. This gets
the hardware out of the doorway and allows the
strips to overlap the door jambs for maximum
seal and air lock. - For in-jamb use header mount, simply order the
exact size you need to span the opening. - Universal mount can also be used when you are
not sure.
- Wall mount is preferred on doorways. This gets
Choosing The Correct Strips
Choosing a Strip and Overlap
Use this simple matrix to choose the ideal strip width and overlap for your application.
Personnel = Foot traffic
Light Duty = Foot traffic and pallet jacks
Heavy Duty = Motorized traffic with occasional foot traffic
Overlaps
Hardware
Static Mount
- Header Mount
- Wall Mount
- Universal Mount
- Threaded Rod Mount (Just a Feature of Universal Mount)
Free-Standing Mount
- Supported from the floor up
- Used in open floors when you can support from above
- Click here for this style
Rolling Hardware
- Allow the strips to roll out of the way
- Ideal for complete access when strips are not needed
- Note the strips roll like a barn door and do not fold up
- Click here for this style
Tube Mount
- Fits up to 2″ diameter pipe
- Each pipe clamp is 4″ wide and holds 2 strips (overlapped)
- Click here for this style
Material
Description
- Clear – Stays clear 20% longer
- Low Temperature Range -40°F
- Phthalate-Free Formulation
- UV Absorber – Strips will not discolor
- Crystal Clear – Extrusion Clear Processing for maximum line of sight
Anti Fungi
- In high moisture applications (food processing, refrigeration, cold chain) a common problem is the growth of fungi on the surface of the PVC strips. We use anti-fungal inhibitors to prevent fungal growth on the surface of the PVC strip or sheet.
Strip Dimensions
- 6″ wide strips | .060″ Thick
- 8″ wide strips | .080″ Thick
- 12″ wide strips | .120″ Thick
Ratings and Certifications
- CFM and NFPA-701 flame retardant certifications
- Exceeds OSHA requirements
- 5 Year warranty on manufacturing defects
Hole Spacing
The pvc strip curtains come with holes punched every 2″ (see example of 8″ wide strip below). This allows the strips to fit the vast majority of strip curtain hardware on the market. Please note that you can also purchase the strips without any mounting holes. Some customers choose to use their own hardware and punch their own mounting holes onsite. Loop style is also available for mounting to bars and tubes. If you want just the strips then on this form select “no hardware.”
FAQ
What is the spacing on the holes for the strips?
- The holes are on 2″ centers as shown below. The below strip is an 8″ wide strip but all of the strips have the same spacing so that the strips fit studded hardware systems.
Should I order the strips a little taller than the opening?
- Only if you are wanting the wall mount hardware. With wall mount hardware order the strips 6″ taller and 6″ wider than the opening you are trying to cover since you are mounting to the face of the opening. Otherwise order the strips to the exact size of the opening.
Are the height of the strips measured from the hole or the top of the strip?
- The height is measured from the top of the strip to the bottom of the strip. The holes are located .75″ down from the top of the strip.
How do you cut the strips in the field?
- You use a utility knife and a straight edge to keep the cut straight.
Are the strips ready to hang and already punched?
- Yes the strips are shipped out and ready to be hung right out of the box.
Ordering
Lead Time
- Ships in 2-3 work days
- Ships UPS or FedEx. You can also specify your shipping account
Warranty
- Strips – 5 year warranty on manufacturing defects
- Hardware – Lifetime warranty on manufacturing defects
