Description

RFQ button used on the AKON Curtains website to submit a quote request for industrial curtain products.

What Do You Need?

Choose your order

Choose Your Layout

Layout

Enter Your Measurements

Choose Your Fullness

Fullness / Drape

How fullness works: Fullness helps the curtain properly cover the full width of your opening. At 0% the curtain is exactly the width you entered; at 50% we make it 50% wider than the width you entered, and at 100% we make it twice as wide.

Choose Your Curtain Material

Curtain Style

Material

Color

40mil Super Duty is a heavier material and adds a shipping surcharge (already included in your price).

Choose Your Hardware (Optional)

Hardware Style

Track Mount Hardware

Static Mount Hardware

Corner Type

Curtain Features (Optional)

Add a Floor Sweep?

Add a Chain Weight?

Add Anchor Straps?

Special notes (optional)

Your Price

Complete your measurements and options above to see your price.

Layout

Fabric area

Style

Material

Your Price

✓ FREE shipping included

Have an agent email me before processing — I have questions ?

Check this and we’ll email you to go over your questions before anything is made.

Keep the Weather Out

Name: Outdoor Industrial Curtains
SKU: outdoorcurtains2x5bluewallmount

Hardware Curtains Accessories Colors Benefits How to Measure

Hardware

Curtain Track

16 gauge galvanized steel tracks
Nylon roller hooks for easy opening
6 mounting styles to connect to various structures
Free standing hardware for up to 20' in height

Static Mount Hardware

Aluminum Angle - Use with self tapping Tek screws to pinch the curtain to the angle.
Grommets Only - You can then use many DIY methods to hang the curtains.
Beam Clamps - Clamps onto the flange of beams, joists and purlins.
Need more ideas? Check out our outdoor curtain anchoring guide.

Attention CA Residents: Prop 65 Warning

Curtains

Opaque Curtains - 18oz, 22oz

Vinyl coated polyester reinforced with scrim
NFPA fire retardant, CFM fire retardant
Finished edges for clean crisp appearance
Double or triple hems used where needed for longevity
Ideal for temperatures going as low as -15° F to 160° F
All colors are the same price
18 oz = .020″ thick, 2.0 oz. per square foot
22 oz = .024″ thick, 2.44 oz. per square foot

Clear Curtains - 20mil and 40mil

Clear double polished PVC
NFPA fire retardant, CFM fire retardant
Finished edges for clean crisp appearance
Double or triple hems used where needed for longevity
Ideal for temperatures going as low as 10° F to 140° F
20 mil = 20mil thick, 1.98 oz. per square foot
40 mil = 40mil thick, 3.95 oz. per square foot

Accessories

Curtain Features

Clear Vision Panels

Vision panels can be added to allow for a clear line of site through the curtain. Standard vision panels are 54" in height but can be made to any size.

Custom Shapes

Need to fill an area that has a peak or an odd shape. We can do that for you. Just provide a hand sketch of the design and we can make it.

Floor Sweeps

A floor sweep seals the open area between the curtain and the floor. It attaches to the main curtain by Velcro. They are 6″ tall and as wide as the entire length of the curtain.

Bottom Pipe Pockets

Add a pocket at the bottom for a pipe to weight down the outdoor curtain. Pipes are not supplied but the pocket is no additional charge.

Chain Weights

For curtains that need to open but also have some weight at the bottom we can add a chain pocket at no additional cost. We can also supply the galvanized 3/16" chain if needed.

Anchor Straps

Webbing straps hold your curtain in place for a light breeze or power washing. These anchors feature tough straps that loop through a D-ring, which is anchored into the cement floor. Typically spaced every 4'.
More anchoring ideas here.

Connecting Curtains / Entry

Velcro

Velcro is used to connect curtain sections together to form larger curtain walls. The Velcro also serves as an access points for larger curtains and makes them easier to install.

Zipper Splits

A zipper can be added for quick entering and exiting. Just like Velcro splits they are great for rapid access into the curtained area.

Sewn In Strip Doors

Strip doors that are sewn into the curtain are ideal for light foot traffic. This allows for quick movement of people into and out of the curtains without opening them.

Colors

Benefits

Key Benefits

Less expensive than rigid walls
Can be taken down quickly when not needed
Easy to store or pull back in the off season
Quick to roll out of way when not in use
Easy to clean with slick surface of Vinyl
Lifetime warranty on all hardware and 1 year warranty on curtains

Common Layouts

AKON can supply just about any layout you can think of for your outdoor curtains. They can be single sided, double-sided, triple sided, four-sided or multiple straights to create complete outdoor curtain enclosures. You simply inform AKON about your desired design and we will have it fabricated exactly as you need it. For customized layouts, sketch your design and upload it using our online RFQ form. See button below.

How to Measure

Width

Measure the distance that you are trying to cover and then add 5% to that dimension and enter it into the width box.
TIP - The reason you want to add 5% is for proper drape of the curtain so it properly covers the span.

Height

Measure the distance from the floor to the above mounting point (from where you would attach the curtain track) and subtract 3 inches, and then input it into the height box.
TIP - If you are not using any hardware, then you don't need to subtract the 3"
TIP - If you want to engage the floor, then select the floor sweep option on this form.

Need More Help? Watch This

Common Questions

What is the spacing from the bottom of the track to the top of the curtain?
Standard curtains have approximately 3.75 to 1″ of a gap from the bottom of the track to the top of the curtain.

What are the dimensions of the track?

Can the track be cut to size on site?
Yes, the track is made to be field cut on site using a hack saw or Sawzall.

How much width does the radius corner add to the length?

The radius corner is 24” diameter. The radius corner will add 2 feet to each dimension.
For example, if you have 120” of curtain track then a radius corner will be make the overall length of side “A” 120”+24”=144”

How does the track go together?
The track is modular in design and will arrive in pieces that have a simple bolt together design.

How close together do I need the track supports?
The track should be supported approximately every 5' with a track support. The farther apart the track supports, the greater the deflection. If you have a relatively short in height curtain then you could space the supports out a little farther. You will receive enough track supports with your order to achieve this 5' spacing.

Can I simply drill straight through the track and into the ceiling / structure?
Yes. This is called a flush mount install and is very common. Simply drill through the middle of the track and use a small wood screw, bolt, Tek screw...ect into your structure. Space the holes about every 3-5'.

How hard is it to install the industrial curtain track?
It is very easy. All of the components simply fit into each other and connect with set screws. The installation is very intuitive. If you have any difficulty simply call or email us and we will walk you through the process.

Will the track rust? Can it be used in wet environments?
The track is Hot-dip galvanizing (HDG) which is often used to protect steel from corrosion in some of the harshest environments imaginable, yet it provides maintenance-free longevity for decades. The corrosion resistance of hot-dip galvanizing varies according to its surroundings but generally corrodes at a rate of 1/30 of bare steel in the same environment.
