Portable Laser Curtain Barriers

Portable Laser Curtain Barriers are mobile laser safety screens designed to protect workers from hazardous laser radiation. Rated up to 575 W/cm² at 1064nm with a 1mm beam diameter, these freestanding barriers are ideal for labs, manufacturing floors, and medical facilities. Configure your barrier below by selecting your layout, material layer, dimensions, skin type, frame, and casters.

  • Rated up to 575 W/cm² Laser Protection
  • Tested at 1064nm, 1mm Beam Diameter
  • Available in Single, Double, Triple, and Quad panel layouts
  • Single, Double, and Triple material layers
  • Standard, Cleanroom, and ESD skin options
  • Standard and Heavy-Duty frame types
  • Locking and Standard casters included
  • Multiple sizes from 4’x6′ up to 10’x6′

    RFQ Button



    Build Your Portable Laser Curtain Barrier Below

$0.00

Description

Step 1 of 5 Choose Layout
Single, Double, Triple, and Quad layout diagram
Step 2 of 5 Choose Panel Size
Step 3 of 5 Choose Material Layer
Step 4 of 5 Choose Skin
Step 5 of 5 Choose Your Frame and Casters
Frame
Casters
Special Request
Your Price
Layout
Panel Size
Material
Skin
Frame
Casters
Your Price
Check this and we’ll email you to go over your questions before anything is made.


Canadian Customers: If shipping to Canada, this product is subject to a 25% tariff fee that will be billed after you place your order. The import fee can vary based on the current legal situation between the USA and Canada.

5 year warranty
Ceiling Corner Connector 90°
Shades
Shades

Overview

In stock and ready to ship Portable Laser Curtains. If you are looking for a laser barrier protection up to 575 W/cm2 Tested at 1064nm with 1mm beam diameter, then a portable laser barrier shield is the best option for you. The divider screens can form a single separation partition, a two-sided enclosure, three-sided enclosure, or four-sided enclosure along with multiple other configurations. We can custom build this portable barrier wall with strong, heavy duty steel hardware, locking casters, and laser rated material. An excellent protection option in a small laser environment.

Benefits

  • 100% laser blackout curtains
  • Color: BLACK
  • NFPA-701 approved for flame resistance
  • Made in the USA
  • Constructed using top of the line material
  • Customization to meet your exact needs
  • Laser curtain material made to order

Common Applications

  • Laboratories
  • Security rooms
  • Hospitals and medical centers
  • Surgical
  • Clinics and health care
  • Dermatology
  • Dental
  • Research & Development
  • Veterinary
  • Electronics Manufacturing Facility
  • Military Testing

Curtain Styles

laser blocking curtains

  • SINGLE LAYER - Rated at 425 W/cm2 for 100 seconds for Class 3B and 4 lasers Size: 58”x96” (Tested at 1064nm with 1mm beam diameter) $
  • DOUBLE LAYER - Rated at 575 W/cm2 for 100 seconds for Class 3B and 4 lasers size: 58”x96” (Tested at 1064nm with 1mm beam diameter) $$
  • TRIPLE LAYER - Rated at 2150 W/cm2 for 100 seconds for Class 3B and 4 lasers size: 58”x96” (Tested at 1064nm with 1mm beam diameter.) $$$

Curtain Upgrades

laser blocking cleanroom curtains

Cleanroom Skins

This protective layer adds cleanroom, antistatic, & antibacterial properties; all in one. It is sewn onto the front and back of the laser safe curtain.

laser blocking esd curtains

ESD Skins

This protective layer adds antistatic properties and is sewn onto the front and back of the laser curtain. By the ASTM D-257 testing methods, the Electrostatic Discharge (ESD) Standard Protective Layer has a surface resistance of 106-107 Ω/sq.m.



Hardware
Layouts
Lead Time

Related Products

Laser Barrier

Curtains

Retractable Laser

Panels

Laser Barrier

Covers

 Portable Laser Curtain Barriers

Foldable Laser

Panels

Laser Curtain

Enclosure

View All

Additional information

Layer

Single Layer, Double Layer, Triple Layer, Quad Layout
Dimensions

4'w x 6'h, 6'w x 4'h, 6'w x 6'h, 6'w x 8'h, 6'w x 10'h, 8'w x 6'h, 8'w x 8'h, 10'w x 6'h
Skin

Standard Skin, Clean Room Skin, ESD Skin
Casters

Casters, Casters – Locking, No Casters
